Manual withdrawal switchgear

Main features of Manual withdrawal switchgear:

Materials: The use of environmentally friendly materials and processes, in line with international environmental standards, reduce the impact on the environment

Manual operation: The user directly manually operates by pulling the handle, lever or rotating the crank. This simple mechanical operation is designed to make the process of removing or inserting parts as easy as possible.

Easy component extraction: The operator uses a hand pull mechanism to remove the circuit breaker module from the panel. Make sure the component is separated from the electrical contacts and can be safely removed for maintenance or replacement.

Guide rail: mounted on a guide rail or track inside the switchgear housing. Easy to slide in and out of the panel smoothly during manual drawing.

Spring-loaded mechanism: The use of a spring or similar mechanism to facilitate the smooth insertion or removal of components.

Interlocking: Mechanical interlocking is used with a manual mechanism to prevent incorrect operation

Ergonomics and safety: ergonomic. The handle or lever is positioned for easy access and operation. In addition, the safety features of the lock or door lock prevent accidental handling and reduce the risk of electric shock or arc flash.

Benefits of manual traction mechanism:

No external power supply: Manual operation requires no additional electrical or mechanical power, making it simpler and more cost effective.

Improved safety: Operators can remove and reinsert components with greater control, reducing the likelihood of accidents and ensuring the safe isolation of electrical components.

Maintenance flexibility: Manual traction system components can easily be removed for testing, maintenance or replacement.

Application: Hand pull mechanism is widely used in medium voltage, high voltage switchgear,

Advantages: Earthquake resistance and corrosion resistance

Conclusion:

The hand-pull mechanism in the hand-out switchgear is designed to provide an easy, efficient and safe way for the operator to manually remove or insert electrical components in the switchgear system. Its main advantages include ease of use, improved safety and reliability, making it an essential feature of electrical maintenance and operation.

Code	Description	Model No	PIC
1041050	MD 1/4  Hand pull mechanism	SLJG-1-8E/4
1041051	MD 1/2  Hand pull mechanism	SLJG-1-8E/2
