35KV Shutter mechanism
  • 35KV Shutter mechanism35KV Shutter mechanism

35KV Shutter mechanism

The 35kV Shutter Mechanism from Ruiziger Technologies is a safety device for use in 35 (kV) electrical equipment. Its main role is to shield or isolate the electrical parts during the operation of the equipment by mechanical or electrical means to ensure that the operator will not come into contact with the live part during the operation of the equipment, to ensure the safety of personnel and to prevent electrical accidents.


Main function

Shielding live parts: Protects high-voltage contacts and other live parts inside the equipment from exposure to the operator or the outside environment while operating the equipment.


Prevent misoperation: Prevent misoperation of the device. The device cannot be turned on without confirming its safety.


Enhanced safety: The operator is not exposed to live parts of the equipment when it is not working.


Compliance with standards: International electrical safety standards are followed to ensure high safety in high-voltage electrical equipment.



Application field

High voltage switchgear: 35kV shielding mechanism is mostly used for 35kV grade high voltage switchgear to ensure that operators do not come into contact with live parts during equipment maintenance or operation.


Substation: In substations, 35kV shielding mechanism is widely used in various switchgear to prevent operators from contacting live parts and ensure the safety of equipment maintenance and overhaul.


Industrial electrical systems: Used in high-voltage electrical equipment in industrial facilities to ensure that no accidents occur during overhaul, operation and maintenance.


Major advantage

Safety: The valve mechanism device can effectively isolate the electric parts, reduce the occurrence of electric shock accidents, and improve the safety of operators.


Misoperation: Ensure that the device is not misoperated in the non-operating state to avoid accidents caused by misoperation of electrical equipment.


Equipment protection: The shielding mechanism can avoid external interference or damage to the equipment and increase the stability and service life of the equipment.




Schematic diagram of assembly

35KV 11SZY.03.240


Model No.and dimensions

序号
名称
代号
数量只/套
1
上连杆焊接 5SZY.1407.1608
2
2 连条 8SZY.1407.1615/28
4
3 上活门推杆焊接 5SZY.1407.1603/4
2
4 下活门推杆焊接
5SZY.1407.1605/6
2
5 大拉簧
8SZY.1407.1618
2
6 下连杆焊接
5SZY.1407.1607
2
7 大连杆焊接
5SZY.1407.1601/2
2
8 轴座
8SZY.1407.0915
2
9 顶杆
8SZY.1407.1609
2
10 支架板
8SZY.1407.1619
6
11 上活门(铁)
5SZY.1407.1626
1
12 下活门(铝)
5SZY.1407.1627
1
