Product Details and Application of Switchgear Insulator Switchgear insulators play a crucial role in the electrical power distribution system, providing essential support and insulation for high-voltage switchgear equipment. Typically made from materials such as ceramic, glass, or polymer composites, these insulators are designed to withstand harsh environmental conditions, including extreme temperatures, humidity, and pollution.

Vertical Bus Switchgear Assembly The vertical busbar bracket is an important component in the switchgear assembly. It is made of epoxy resin, a common insulating material, which has excellent electrical insulation properties, durability and resistance to moisture and temperature changes. The vertical busbar bracket produced by Reziger can be flexibly configured according to different power requirements and application scenarios to meet the individual needs of users. The function is to fix the vertical busbar (a conductive metal rod carrying current) in the switchgear chassis to ensure that the busbar is correctly aligned and insulated from the surrounding environment to ensure that the current will not be damaged or overheated.

Switchgear Door Lock Bent Plate – Product Details and Applications The Switchgear Door Lock Bent Plate is a critical mechanical component designed to enhance the safety and operational integrity of electrical switchgear systems. It serves as a key element in the door locking mechanism, ensuring the secure closure of switchgear cabinet doors. Typically made from robust materials such as stainless steel or zinc-coated metal, the bent plate offers durability, resistance to corrosion, and strength under mechanical stress, ideal for both indoor and outdoor switchgear installations. The bent plate features precise bends and dimensions to fit perfectly within the locking assembly, working seamlessly with handles, latches, or electromagnetic locks. It plays a crucial role in achieving smooth mechanical alignment between the door and frame, preventing accidental door openings caused by external vibrations or impact. Some variants are designed to support additional locking mechanisms, such as padlocks, to offer enhanced access control and security during maintenance or operation.

The Switchgear M12 Shaft is a precision-engineered component designed to enhance the functionality and reliability of electrical switchgear systems. This shaft is characterized by its M12 threading, which ensures a secure and stable connection in a variety of switchgear assemblies. Manufactured from high-grade stainless steel or durable alloy materials, it offers exceptional resistance to corrosion, wear, and mechanical stress, making it ideal for demanding industrial environments.

The Switchgear Drawer Handle Assembly is an essential safety device designed to enhance the operational reliability of electrical switchgear systems. This mechanism ensures that the drawer can only be moved to the service or test position when specific conditions are met, preventing accidental disconnections or hazardous situations.

The 3 Phase Connection Support 630A is an essential component designed for efficient electrical connections in medium to high voltage switchgear systems. This support is engineered to handle currents up to 630A, ensuring optimal performance and reliability in demanding environments.
